Product Specifications
| Item | Unit | AR-2216 |
| X/Y/Z Axis Travel | mm | 2200/1400/1600 |
| Distance from Spindle End to Worktable Surface | mm | 435-2035 |
| Distance from Spindle Center to Worktable Surface | mm | 465-1875 |
| Worktable Size | mm | 1400*1200 |
| Worktable T-slot (Number - Size-Pitch) | mm | 5-22*215 |
| Maximum Worktable Load Capacity | kgs | 6000 |
| Maximum Speed | rpm | 6000 |
| Recommended Spindle Motor Power | kW | 18.5 |
| Spindle Transmission Method | Direct Drive | |
| Spindle Taper (Model/Mounting Dimensions) | kW | BT 50-190 |
| Recommended X/Y/Z Axis Motor Power | 703/453/453B | |
| X/Y/Z Axis Rapid Traverse Speed | m / min | 1-8000 |
| Cutting Feed | 10/10/10 | |
| Positioning Accuracy | mm | 0.008/300 |
| Repeatability Accuracy | mm | 0.005/300 |
| X/Y/Z Axis Ball Screw Specification | 6310/6310/6310 | |
| X/Y/Z Axis Linear Guide Specification | 65 Roller/55 Roller/65 Roller | |
| Tool Magazine Capacity | 40T Hydraulic Swivel Tool Magazine | |
| Maximum Tool Diameter (Full Tool / Adjacent Tool) | mm | 125/245 |
| Maximum Tool Length | mm | 400 |
| Maximum Tool Weight | kg | 25 |
| Machine Dimensions | mm | |
| Machine Weight | kg | 22000 |
